Triple Head Multiple Boring Machine
600000.00 INR/Unit
Product Details:
- Dimension (L*W*H) 3800x2500x1500 Millimeter (mm)
- Product Type Boring Machine
- Computerized Yes
- Automatic Grade Automatic
- Voltage 380 Volt (v)
- Weight (kg) 1000 Kilograms (kg)
- Click to View more
X
Triple Head Multiple Boring Machine Price And Quantity
- 1 Unit
- 600000.00 INR/Unit
Triple Head Multiple Boring Machine Product Specifications
- 3800x2500x1500 Millimeter (mm)
- Boring Machine
- Automatic
- Yes
- 380 Volt (v)
- 1000 Kilograms (kg)
Triple Head Multiple Boring Machine Trade Information
- 1 Unit Per Month
- 1 Months
Product Description
Triple Head Multiple Boring Machine is suited for the process of Panel Drilling, Ply Drilling and Lock Drilling.The machine is equipped with rotating vertical boring heads. It has spindles for the execution of holes in a line. The machine is suited for wardrobe side processing and is electronically programmed. It has quick change spindles, strengthened frame, operative pneumatic heads and speedy setting for controlling the drilling depth. It ensures efficient operation on account of smart touch PLC control panel. It is a better solution for long panels and provides convenient operation.
Technical specifications of Triple Head Multiple Boring Machine
| Spindle speed | 2840 rpm |
| Suitable voltage | 380 v |
| Weight | 1000 kg |
| Height of working platform off ground | 900 mm |
| Dimension | 3800 x 2500 x 1500 mm |
| Max drilling diameter | 35mm |
| Drilling depth | 60mm |
| Max processing pitch | 2800x 640X140 mm |
| Minimum processing pitch | 120x32 mm |
| Total power of motor | .5 kw x 3 |
| Installation pitch of drilling head | 10mm |
| Compressed air pressure | 6 - 8 kg/cm 2 |
| Total number of drilling shafts | 21 x 3 |
